کانکتور هارتینگ Heavy Duty connector

Specification:

Basic	Model	ATO-HDCN-HA-010-1	ATO-HDCN-HA-010-2	ATO-HDCN-HA-010-3	ATO-HDCN-HA-010-4	ATO-HDCN-HE-010-1	ATO-HDCN-HE-010-2	ATO-HDCN-HE-010-3	ATO-HDCN-HE-010-4
	Shipping weight	1kg
	Standard	DIN EN 60 664-1, DIN EN 61 984
	Number of pins	10 pin + PE
	Certificate	CCC, CE, ROHS, RU, CSA, TUV
Inserts	Item	HA-010-M	HA-010-M	HA-010-M	HA-010-M	HE-010-M	HE-010-M	HE-010-M	HE-010-M
	Working current	16A
	Working voltage	250V	250V	250V	250V	500V	500V	500V	500V
	Rated pulse voltage urms	4kV	4kV	4kV	4kV	6kV	6kV	6kV	6kV
	Pollution degree	3 (C)
	Insulation resistance	≥10¹⁰Ω
	Material	Polycarbonate
	Working temperature Range	-40℃~+125℃ (-40℉~+257℉)
	Flammability according to UL94	V0
	Working voltage according to UL / CSA	600V
	Insertion / withdrawal cycles	≥500
Contacts	Item	HA-010-F	HA-010-F	HA-010-F	HA-010-F	HE-010-F	HE-010-F	HE-010-F	HE-010-F
	Material	Copper alloy
	Surface treatment	Silver/ Gold plating
	Contact resistance	≤1mΩ
	Wiring form	Screw connection
	Wire specification	0.75-2.5mm² AWG 18-14
	Tightening torque	0.5N·m
Shell	Hood item	H10A-TS-RO-M20	H10A-TG-RO-M20	H10A-TS-RO-M20	H10A-TG-RO-M20	H10B-TS-M20	H10B-TG-M20	H10B-TS-M20	H10B-TG-M20
	Hood thread	M20	M20	M20	M20	M20	M20	M20	M20
	Housing item	H10A-AG-B	H10A-AG-B	H10A-SGRLB-2M20	H10A-SGRLB-2M20	H10B-AG	H10B-AG	H10B-SGR-2M20	H10B-SGR-2M20
	Housing thread	–	–	2*M20	2*M20	–	–	2*M20	2*M20
	Material	Cast zinc	Cast zinc	Cast zinc	Cast zinc	Cast aluminum	Cast aluminum	Cast aluminum	Cast aluminum
	Surface treatment	Powder-coated, gray
	Interlocking element	Interlocking method: metal elastic pressing, material: galvanized iron/ stainless steel				Interlocking method: metal elastic pressing, material: galvanized iron
	Sealing element	NBR
	Applicable temperature range	-40℃~+125℃ (-40℉~+257℉)
	Flammability class	V0
	Protection class	IP65
